Anthem STR Integrated Amplifier Black
Choose options
| PHONO PREAMPLIFIER The phono preamplifier is suitable for moving magnet and high-output moving coil cartridges |
||
| Input Impedance | 100 Ω (MC), 47 kΩ (MM) | |
| Input Capacitance | 270 pF (MM) | |
| Maximum Input (at 1 kHz for <0.1% THD 20 Hz - 20 kHz) | 3.6 mV (MC), 37.7 mV (MM) | |
| Gain (default at 1 kHz, user adjustable ± 20 dB) | 55 dB (MC), 35 dB (MM) | |
| RIAA Response | ± 0.1 dB (20 Hz to 20 kHz) | |
| THD+N (at 1 kHz, 20 Hz - 20 kHz BW, 2 V rms output) | 0.008% (MC), 0.005% (MM) | |
| S/N Ratio (at 1 kHz, IEC-A, 2 V rms output) | 82 dB (MC), 96 dB (MM) | |
| PREAMPLIFIER | ||
| Frequency Response | ||
| digital-in, 192 kHz | 10 Hz - 50 kHz (+0.00, -0.50 dB) | |
| digital-in, 96 kHz | 10 Hz - 45 kHz (+0.00, -0.50 dB) | |
| digital-in, 44.1 kHz | 10 Hz - 20 kHz (+0.00, -0.03 dB) | |
| analog-in, DSP mode | 10 Hz - 40 kHz (+0.02, -0.20 dB) | |
| analog-in, direct mode | 10 Hz - 80 kHz (+0.00, -0.10 dB) | |
| THD+N (at 1 kHz, 20 Hz - 20 kHz BW, 2 V rms output) | ||
| digital-in, 44.1 kHz, 0 d BFS | 0.0008% | |
| analog-in, DSP mode, 1 V rms input | 0.001% | |
| analog-in, direct mode, 1 V rms input | 0.0020% | |
| SNR (at 1 kHz, IEC-A, 2 V rms output) | ||
| digital-in, 44.1 kHz, 0 d BFS | 112 dB | |
| analog-in, DSP mode, 2 V rms input | 110 dB | |
| analog-in, direct mode, 2 V rms input | 120 dB | |
| Maximum Output (<0.1% THD) | 2.2 V rms except analog-direct 3.3 V rms | |
| XLR Configuration | Pin 1: Ground, Pin 2: Normal, Pin 3: Inverted | |
The revolutionary STR Integrated Amplifier is based on an entirely new technological platform, for true benchmark performance in stereo amplification. More power, more control, more connection options, and the most advanced technology available in a single, easy-to-use component.
Designed, engineered, and Crafted in Canada, the STR Integrated Amplifier combines the benefits of an advanced preamp with the power of a massive amplifier and processor. It includes leading-edge DAC, onboard Anthem Room Correction (ARC®®), customizable bass manager for mono or stereo sub outs, MM and MC phono inputs—far more than the average integrated amp.
And it includes new generations of many of Anthem’s award-winning, audiophile-loving, review-praised digital signal processing innovations, delivering a noticeably higher level of audio performance realism.
This is the integrated amplifier with the power, features, connections and control to fuel your two-channel dreams, today and into tomorrow.
