Specifications and Features:

• Signal-to-noise ratio: “A” Weighted 106 dB
• Total harmonic distortion: (THD) Unweighted 20 Hz-20 kHz, +0, – 0.003 dB
• Inputs:
• Analog Audio: (1) Pair Balanced via XLR connectors
  (4) Pairs Single-ended via RCA connectors
• Digital Audio: (10) HDMI 2.0 (4 w/HDCP 2.2) via HDMI connectors (9 on rear, 1 on front)
  (3) EIAJ optical via Toslink connectors
  (3) Coaxial via RCA connectors
• Digital Video: (10) HDMI 2.0 (4 w/HDCP 2.2) via HDMI connectors (9 on rear, 1 on front)
• Analog Video: (3) Component Video via RCA connectors
  (2) Composite Video via RCA connectors
• Outputs:
• Analog Audio:(9) Balanced via XLR Connectors
  R, L, C, SR, SL, SBR, SBL, S1, S2
  (9) Single-ended via RCA Connectors
  R, L, C, SR, SL, SBR, SBL, S1, S2
  (1) Zone 2 Output
  (2) Single-ended via RCA connectors
• Digital Audio:  (2) HDMI via HDMI connector
• Digital Video: (2) HDMI via HDMI connector
  Both Include Audio Return Channel

• Control / Update: (1) IR Receiver for Remote Control
  (1) RS-232 via DB9 Female Connector Straight Wired
  (1) RC-5 via 1/8″ stereo “trs” Receptacle
  (1) Ethernet via RJ-45 Connector
  (1) Mini USB used for firmware updates
  (1) 12vdc Remote Trigger Input via 1/8″ Mono receptacle
  (1) 12vdc Remote Trigger Outputs via 1/8 Mono receptacles

• Digital Decoding Modes: Dolby True HD
  Dolby Digital Plus
  Dolby Digital 5.1
  Dolby Digital EX
  Dolby Pro Logic IIX
  DTS-HD Master Audio
  DTS-HD High Resolution Audio
  DTS 5.1
  DTS ES Discrete 6.1
  DTS ES Matrix 6.1
  DTS Neo:6
  PCM 5.1
  PCM 7.1

• Maximum Input: Balanced 6.3 Vrms
  Single Ended 3.15 Vrms

• Maximum Output: Balanced 16.7 Vrms
  Single Ended 8.35 Vrms.

• Audio Input Impedance: Balanced 58K Ω
  Single Ended 58K Ω

• Audio Output Impedance: Balanced 100 Ω
  Single Ended 100 Ω

• Power Consumption: Stand-by 2w
  Operation 59w

• Dimensions: Inches (L) 16.83 x (W) 17.06 x (H) 3.47
  Centimeters (L) 42.76 x (W) 43.33 x (H) 88.1
