• SC-LX704
SC-LX704 SC-LX704





Equipped with the 6th generation of Direct Energy HD Amplifier, the SC-LX704 is worthy of being your home cinema’s centerpiece, and an ideal combination for Pioneer’s flagship universal disc player. Two ES9026PRO DACs ensure quality audio reproduction, while MCACC Pro Auto Room Tuning technology with Full Band Phase Control brings out the best from 3D surround sounds of IMAX® Enhanced, Dolby Atmos®, and DTS:X. Enjoy rich, vibrant sound with PQLS jitterless transmission. The new Audio Exclusive Mode and AV Direct Mode enhance detailed sound reproduction by turning off the unused functions to eliminate unwanted noise.

    Specifications and Features:


      • Channels: 9
      • Amplification Type: Class D (Direct Energy HD)
      • 205 W x 9ch (6 ohms, 1 kHz, THD 1 %, 1ch Driven IEC)


      • Advanced Direct Construction
      • Rigid Trans-Stabilizer
      • Anti-Standing Wave Insulator
      • AC Inlet Type Thick Cable

        Audio Features:

        • IMAX Enhanced
        • Dolby Atmos®, Dolby Surround Upmixer
        • DTS:X®, DTS Neural:X® Upmixer
        • Reflex Optimizer
        • Dolby Atmos Height Virtualizer
        • Dolby® TrueHD, Dolby Digital Plus
        • DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS Express
        • DSD Direct Playback via Network/USB (11.2, 5.6, 2.8 MHz/2 ch)
        • DSD Disc (SACD) Playback via HDMI (2.8 MHz/2 ch, 5.1 ch)
        • Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus™ floating-point DSP (TI)
        • 384 kHz/32-bit D/A Conversion with ES9026PRO x 2
        • Enhanced Audio Return Channel (eARC) on HDMI
        • MCACC Pro Auto Room Tuning
        • PQLS Jitterless Sound Transmission
        • PQFA Jitterless Sound Processing for Network/USB
        • Audio Exclusive Mode
        • AV Direct Mode
        • Advanced Sound Retriever (2ch)
        • Advanced Surround Modes

        Video Features:

        • Ultra HD Pass-through with HDCP 2.3 (4K/60p/4:4:4/24-bit, 4K/24p/4:4:4/36-bit, 4K/60p/4:2:0/36-bit)
        • HDR10, HLG and BT.2020 Compliant Wide Colour Gamut Signal Pass-through
        • Dolby Vision™ Compatible
        • Ultra HD Upscaling (1080p to 4K)
        • 3D Ready (Blu-ray Disc™, Broadcast, and Games)
        • Deep Colour (36-bit), “x.v. Colour”


          • Power Requirements: AC 220-230 V, 50/60 Hz
          • Power Consumption/Standby: 310 W/0.2 W
          • Dimensions (W x H x D): 435 x 185 x 440 mm
